Specifications

• Input Circuit: Floating
• Patient Current Leakage: < 10 µA
• Input Circuit Current: < 0.1 µA
• CMRR: > 100 dB
• Noise Level: < 15 µVp-p
• Calibration Voltage: 1 mV ± 2%
• Printing Output: 12 Channel
• Paper Size: 210 mm
• Power Source: Electricity
• Warranty: 1 Year
• A/D Converter: 24-bit
• Shelf Life: 2 Years
• Quality Certification: ISO 1348
• Instrument Classification: Class II
• Leads: Standard

Description

• Patient information input support
• Historical data review and printing functionality
• Built-in rechargeable Li-ion battery with AC/DC power conversion
• Sleep mode for energy saving and extended LCD life
• Portable design with hidden handle for easy carrying
• Lead-off detection and paper-out detection function
• 7 levels of adjustable print thickness
• Supports 110–230V, 50/60Hz AC power supply

Features

• 12-lead ECG synchronous sampling system
• Thermal printer with 80 mm paper and synchronized printing
• 10.2” color touch screen with button and touch operation
• Automatic measurement, calculation, and analysis
• Waveform freezing function
• Supports USB flash disk and SD memory
• Data transmission to PC via RS232 / USB
