Product Introduction

Brand: OSC

Model: OSC-ECG-600G

OSC-ECG-600G is a six-channel electrocardiograph designed for accurate ECG monitoring and analysis. It supports 12-lead simultaneous acquisition and delivers high-quality ECG waveforms using advanced digital signal processing.

The device features auto/manual recording, waveform display, and intelligent analysis functions, making it suitable for hospitals, clinics, and diagnostic use.

Features

• 800 × 480 TFT color LCD display for clear ECG waveform and status view
• Touch screen with soft keyboard for easy operation
• 12-lead ECG simultaneous acquisition with digital signal processing
• High-quality ECG signals using AC, baseline, and EMG filters
• Simultaneous display of 3/6/12 lead ECG waveforms
• Multiple recording formats: 2×6+1, 2×6, 3×4, 3×4+1, 4×3, 4×3+1, 6×2, 6×2+1
• Auto measurement and auto diagnosis of ECG parameters
• Lead-off detection and paper shortage indication
• Multi-language interface support
• Built-in storage for more than 1000 ECG cases
• Review mode for saved ECG waveforms and reports

Specifications

• Channels: 6 Channels
• Power Supply: AC 100V – 240V, 50/60 Hz (AC/DC supported)
• Battery: Built-in lithium polymer rechargeable battery
• Battery Backup: Up to 4 hours standby
• Printing Capacity: 150 ECG reports or 90 minutes continuous printing
• Safety Class: Class I, Type CF applied part (with defibrillation protection)
• Fuse Specification: 2 pcs, 5 × 20 mm, T1.6A / 250V

Description

The ECG-600G system samples 12-lead ECG signals simultaneously and prints waveforms using a thermal printing system. It supports both automatic and manual modes, offering efficient ECG monitoring and reporting.

It is designed to enhance workflow efficiency with intelligent ECG parameter analysis, waveform interpretation, and easy data management for clinical use.
