Product Specifications

• Weight: 1.5 kg
• Syringe Size: 2 ml (also available in 5 ml, 10 ml, 20 ml, 30 ml, 50/60 ml)
• Accuracy: ±2%
• Power Consumption: < 55 VA
• Dimensions: 270 × 140 × 80 mm (W × D × H)

Alarms

• Battery exhausted alarm
• Low battery alarm
• Near end alarm
• VTBI finished alarm
• Incorrect syringe handling alarm

Bolus Rate

• 2 ml syringe: 100 ml/h
• 5 ml syringe: 150 ml/h
• 10 ml syringe: 400 ml/h
• 20 ml syringe: 600 ml/h
• 30 ml syringe: up to 1000 ml/h

Volume Range

0.01 ~ 9999.99 ml (step by 0.01 ml)

Flow Rate Range

• 2 ml: 0.01 ~ 100 ml/h
• 5 ml: 0.01 ~ 150 ml/h
• 10 ml: 0.01 ~ 400 ml/h
• 20 ml: 0.01 ~ 600 ml/h
• 30 ml: 0.01 ~ 1000 ml/h

KVO Rate

• Flow Rate ? 10 ml/h ? KVO rate: 3 ml/h
• Flow Rate 1 – 10 ml/h ? KVO rate: 1 ml/h
• Flow Rate < 1 ml/h ? KVO maintained

Occlusion Pressure

Maximum: 130 kPa | Minimum: 26 kPa (9 adjustable levels)

Power Supply

• AC Input: 100V ~ 240V, 50/60 Hz
• DC Output: 15V / 2A
• Device Input Power: DC 15V

Battery

• Lithium Battery (Nominal Voltage: 10.8V)
• Backup Time: More than 6 hours

Classification

Class II, Type CF, IPX2

Minimum Order Quantity

1 Unit
